Turn Signal
–
FLASHING or SOLID
Button #3 or #4
|
The T05 default setting
for the turn signals is a SOLID signal.
This allows the technician to accurately read the current
draw of this circuit.
To change the setting to a FLASHING
signal, press and hold the #3 or #4 button for 5 second.
Activating this circuit will now result in an intermittent
(FLASHING) signal.The buzzer will also be audible if
this option is activated.
To revert to the SOLID signal,
simply press and hold the #3 or #4 for 5 second again.
|
Activation of Brake Light
or Electrical Brakes
Button #6
|
To activate the electrical
brake function, press and hold the button #6 for 10 seconds.
The Electrical Brake function is activated once the brake
light on the Trailteck starts blinking
You will witness the activation
of the electrical brake once.
The output voltage will drop
slightly to permit the activation of the electrical
brake system.
|
| Alarm Function |
Hold for 5 seconds to
activate/deactivate the audible signal coming from the
T05 when a remote function is activated
|
| Freeze Function |
For safety purposes,
the T05 is equipped with a lock out feature. To activate
/ deactivate the Freeze function, hold the Freeze button
for 5 seconds. Freeze mode will result in freezing all
functions on the T05 panel and remote control.
This is especially important when working around the air
brake system.
|
